| Place of Origin: | CHINA |
|---|---|
| Brand Name: | SKYLYNN or OEM, ODM |
| Certification: | ISO, ROHS, CE |
| Minimum Order Quantity: | 2KM |
| Packaging Details: | WOODEN DRUM |
| Delivery Time: | 5-10 DAYS |
| Payment Terms: | T/T, L/C, WEST UNION |
| Supply Ability: | 100,000 cores |
| Model NO.: | GYTC8A | Crush Resistance: | 300/1000 N/100mm |
|---|---|---|---|
| Numerical Aperture: | .200±0.015NA | Bending Radius: | 105/210 |
| High Light: | dielectric armored fiber optic cable 144F,dielectric armored fiber optic cable GYTC8A,Multimode fiber optic om1 om2 om3 |
||
The fibers, 250μm , are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A steel wire locates in the center of core as a metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular cable core. After an Aluminum Polyethylene Laminate (APL) moisture barrier is applied around the cable core, this part of cable accompanied with the stranded wires as the supporting part are completed with a polyethylene (PE) sheath to be figure 8 structure.
Low attenuation and dispersion, special control of exceed length ensure the good transmission performance in varying environment.
Excellent mechanical performance
Good flexibility and bending performance
Small outer diameter, lightness and compact construction
| G.652 | G.655 | 50/125μm | 62.5/125μm | ||
| Attenuation | @850nm | ≤3.0 dB/km | ≤3.0 dB/km | ||
| (+20℃) | @1300nm | ≤1.0 dB/km | ≤1.0 dB/km | ||
| @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | |||
| @1550nm | ≤0.22 dB/km | ≤0.23dB/km | |||
| Bandwidth (Class A) | @850nm | ≥500 MHz·km | ≥200 MHz·km | ||
| @1300nm | ≥1000 MHz·km | ≥600 MHz·km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm | |||
| Cable Type | Fiber Count | Tubes | Fillers | Cable Diameter mm | Cable Weight kg/km | Tensile strength | Crush resistance | Bending radius |
| Long/Short term | Long/Short term | Static/Dynamic | ||||||
| (N) | (N/100mm) | (mm) | ||||||
| GYTC8A-6 | 6 | 1 | 5 | 10.4*18.3 | 150 | 2500/5000 | 300/1000 | 105/210 |
| GYTC8A-12 | 12 | 2 | 4 | 10.4*18.3 | 150 | 2500/5000 | 300/1000 | 105/210 |
| GYTC8A-24 | 24 | 4 | 2 | 10.4*18.3 | 150 | 2500/5000 | 300/1000 | 105/210 |
| GYTC8A-36 | 36 | 6 | 0 | 10.4*18.3 | 150 | 2500/5000 | 300/1000 | 105/210 |
| GYTC8A-48 | 48 | 4 | 2 | 11.3*19.2 | 170 | 2500/5000 | 300/1000 | 115/330 |
| GYTC8A-60 | 60 | 5 | 1 | 11.3*19.2 | 170 | 2500/5000 | 300/1000 | 115/330 |
| GYTC8A-72 | 72 | 6 | 0 | 11.3*19.2 | 170 | 2500/5000 | 300/1000 | 115/330 |
| GYTC8A-96 | 96 | 8 | 0 | 12.7*20.6 | 200 | 2500/5000 | 300/1000 | 130/260 |
| GYTC8A-144 | 144 | 12 | 0 | 15.5*23.4 | 270 | 2500/5000 | 300/1000 | 155/310 |
| GYTC8A-192 | 192 | 8 | 0 | 14.5*22.4 | 250 | 2500/5000 | 300/1000 | 145/290 |
| GYTC8A-288 | 288 | 12 | 0 | 18.1*26.0 | 350 | 2500/5000 | 300/1000 | 185/370 |
